Reference media in your own bucket (BYOB) using agent spans

Use this technique when the media you want to see in Weave already lives in your own bucket:

Frames from a video pipeline.
Screenshots from a browser agent.
Images a model wrote to S3.

Instead of re-uploading those bytes into Weave, you log the object’s URI as a string and Weave renders the image or video inline from your bucket. Only the URI is sent to Weave; the bytes stay in your bucket. Logging a 2 GB video costs the same as logging its path. This is different from logging media with the Content API, which reads the bytes and stores them in Weave.

This is a Weave feature and is separate from platform BYOB (secure storage connector), which backs W&B artifact and run storage. Reference media buckets are configured per team and only need read access.

How it works

Reference media rendering works in three steps:

You store a media object in your bucket, for example s3://[YOUR-BUCKET]/frames/000123.png.
You log that URI as a string value anywhere in a trace: an Op input or output, or an agent tool result. The field name does not matter.
When you open the trace, Weave resolves the URI to a short-lived presigned URL and renders it inline. The file extension decides how it renders. Common image formats (such as .png, .jpg, .gif) and video formats (such as .mp4, .mov, .webm) render inline. Other formats render as a download link.

Weave only resolves URIs that point at a bucket registered for your team. Supported schemes are s3:// and gs://.

Prerequisites

This feature is supported only in W&B Multi-tenant Cloud.
A W&B account and API key.
A cloud storage bucket you control (S3 or GCS), containing at least one object.
Organization admin permissions. Adding a reference bucket requires the same permission as creating a team in the organization.

Configure your bucket

Grant W&B read access to the bucket and allow the browser to fetch objects with CORS. When you view a trace, W&B presigns a short-lived download URL for each referenced object. Grant the W&B integration principal read access on the bucket so presigning can succeed. This is read-only access for inline rendering.

AWS S3
Google Cloud Storage

Apply a bucket policy that grants the W&B integration principal s3:GetObject. Save the following as bucket-policy.json, replacing [YOUR-BUCKET] with your bucket name:

{
  "Version": "2012-10-17",
  "Id": "WandBAccess",
  "Statement": [{
    "Sid": "WandbAccess",
    "Effect": "Allow",
    "Principal": {"AWS": "arn:aws:iam::725579432336:role/WandbIntegration"},
    "Action": "s3:GetObject",
    "Resource": "arn:aws:s3:::[YOUR-BUCKET]/*"
  }]
}

Then apply it to your bucket:

aws s3api put-bucket-policy --bucket [YOUR-BUCKET] --policy file://bucket-policy.json

Apply a CORS configuration so the app can fetch objects in the browser. Save the following as cors.json:

{
  "CORSRules": [{
    "AllowedHeaders": ["*"],
    "AllowedMethods": ["GET", "HEAD"],
    "AllowedOrigins": ["https://wandb.ai"],
    "ExposeHeaders": ["ETag"],
    "MaxAgeSeconds": 3000
  }]
}

Then apply it to your bucket:

aws s3api put-bucket-cors --bucket [YOUR-BUCKET] --cors-configuration file://cors.json

If an object is encrypted with a customer-managed KMS key, its key policy must also grant arn:aws:iam::725579432336:role/WandbIntegration kms:Decrypt. The bucket policy alone is not sufficient.

Grant the W&B integration service account roles/storage.objectViewer on the bucket. Replace [YOUR-BUCKET] with your bucket name:

gcloud storage buckets add-iam-policy-binding gs://[YOUR-BUCKET] \
  --member="serviceAccount:wandb-integration@wandb-production.iam.gserviceaccount.com" \
  --role="roles/storage.objectViewer"

Apply a CORS configuration so the app can fetch objects in the browser. Save the following as cors.json:

[{
  "origin": ["https://wandb.ai"],
  "method": ["GET", "HEAD"],
  "responseHeader": ["ETag"],
  "maxAgeSeconds": 3000
}]

Then apply it to your bucket:

gcloud storage buckets update gs://[YOUR-BUCKET] --cors-file=cors.json

At this point, W&B can read objects from your bucket, and the Weave UI can fetch them in the browser.

Register the reference bucket

Go to your team settings page (https://wandb.ai/[YOUR-TEAM]/settings).
In the Reference buckets section, select Add bucket.
Select your cloud provider (AWS or Google Cloud).
For the bucket name, enter [YOUR-BUCKET] only — without the s3:// or gs:// prefix.
For the object key, enter the key of an existing object in the bucket, for example photos/cat.png (the object key only, not a full URL). W&B reads this one object to confirm it has read access and that CORS is configured correctly. This checks access only; once verified, presigning works for any object in the bucket.
Optionally, select Test connection to validate the configuration without saving.
Select Add bucket to save.

The Add reference bucket dialog in team settings, with fields for the cloud provider, the bucket name, and an existing object key, plus Test connection and Add bucket buttons.

Until the bucket is registered, referenced URIs do not render. Registration is what lets Weave presign and display the object.

Log a media reference using agent spans

Return a bucket URI as an agent tool result and Weave renders it inline in the Agents view, on the tool call that produced it. The following example opens a conversation, a turn, and a tool span, and sets a bucket URI as the tool’s result. Replace [YOUR-TEAM], [YOUR-PROJECT], and [YOUR-BUCKET] with your own values.

Python
TypeScript

import weave

weave.init("[YOUR-TEAM]/[YOUR-PROJECT]")

# A tool that returns an object that already lives in your bucket.
def get_frame(frame_id: int) -> str:
    return f"s3://[YOUR-BUCKET]/frames/{frame_id:06d}.png"

with weave.start_conversation(agent_name="frame-labeler") as conversation:
    with weave.start_turn(user_message="Show me frame 123", model="gpt-4o-mini"):
        with weave.start_tool(
            name="get_frame",
            arguments='{"frame_id": 123}',
            tool_call_id="call_1",
        ) as tool:
            # The result is a bucket URI string; it renders inline in the Agents view.
            tool.result = get_frame(123)

import * as weave from 'weave';

await weave.init('[YOUR-TEAM]/[YOUR-PROJECT]');

// A tool that returns an object that already lives in your bucket.
function getFrame(frameId: number): string {
  return `s3://[YOUR-BUCKET]/frames/${String(frameId).padStart(6, '0')}.png`;
}

const conversation = weave.startConversation({agentName: 'frame-labeler'});
const turn = weave.startTurn({model: 'gpt-4o-mini'});
const tool = weave.startTool({
  name: 'getFrame',
  args: JSON.stringify({frameId: 123}),
  toolCallId: 'call_1',
});
// The result is a bucket URI string; it renders inline in the Agents view.
tool.result = getFrame(123);
tool.end();
turn.end();
conversation.end();

This example uses Weave agent spans. For the full multi-turn setup, including LLM calls and a complete agent loop, see the custom agents quickstart.

View the reference in Weave Agents

Open the conversation from the link that weave.init() prints. The referenced image or video renders inline in the Agents view, on the tool call that returned the URI. If Weave can’t resolve a URI, for example because the object is missing or the bucket isn’t registered, it shows the plain URI string.

A referenced image rendering inline on a tool call in the Weave Agents view, resolved from a bucket URI that points at an object in your own cloud bucket.
